Waterproof IP67 LED Street Light Module Custom Made Silver Finish 17683

Waterproof IP67 LED Street Light Module Custom Made Silver Finish 17683



在线咨询
产品介绍

Waterproof IP67 LED Street Light Module Outdoor Light Field Flood Light 50w



Product Specification

Model No.

DK173-17683

Input Voltage

DC48V

Input Current

900mA

Product Finish

Silver

Power

30W

Luminouse Flux

4500LM

LED Chip

5050 (12Pcs)

Beam Angle

151x81

Color Option

warm white/Natural White/ Cool white

CRI

Ra>70

Work Environment

Temperature:-40℃-50℃

Humidity:10%-95%

IP Level

IP66

Lifespan

>50,000Hours

Heat Sink Material

Aviation aluminum

Dimensions

L176xW71xH47mm

Lens Material

PMMA

Connector

M15

Weight

0.33kg





Features:

  • Use prefect anodizing aluminum alloy heatsink,improve the service life of radiator.

  • Excellent operating temperature -40°C ~ 50°C

  • High performance design with multi-chips package 5050 L E D source.Stable performance,low light failure and NO dead lights.

  • Variety beam angles, 140x30°/148x50°/150x60°/140°/30°/60°/90°/80x40°

  • High safety, low voltage input is safety for peopel, which effectively prevents electric shock and electric leakage.

  • Easy to assemble and maintain with national standard M15 electrical interface,achieved plugged and play,only need loosening the screw during maintenance.

  • Green product,no UV,IR radiation or mercury pollution.Passed IEC62471.

  • With excellent housing design reach IP66 rating.

  • Life-span over 50,000 hours,5 years warranty.



Main parameter:

LED Light Source

5050x 12pcs

Output Power

15w 20w 30w 40W

Luminous Flux

2160lm,3400lm,4800lm,6000lm

Input Current

250ma,420ma,630ma,830ma

Input Voltage Range

48Vdc

Lighting Distributions

140x30°/148x50°/150x60°/140°/30°/60°/90°/80x40°

CCT

3000K, 4000K, 5000K, 6000K

IP Class

IP66

Product Fixture Size

200*72*55mm, 430g

Packing Details

xx*xx*xxmm (40pcs), 19.8kgs
